Overview

The aim of this activity is for students to visualize organic molecules and understand how to convert from a three dimensional model to a two dimensional drawing. The types of structural representation used are: Fisher projections, Newman projections and perspective formulas.

In class 1, a lecture is completed introducing stereochemistry with the objective of understanding how to assign absolute configurations to chiral carbons. (The lecture covers: R/S configurations on chiral centres and molecules containing 1 or 2 chiral centres). Enantiomers and diastereomers are also introduced in class 1.

Just before the Class 2 starts, the instructor sets up the active learning classroom.

There are 7 ...

Read More +

The aim of this activity is for students to visualize organic molecules and understand how to convert from a three dimensional model to a two dimensional drawing. The types of structural representation used are: Fisher projections, Newman projections and perspective formulas.

In class 1, a lecture is completed introducing stereochemistry with the objective of understanding how to assign absolute configurations to chiral carbons. (The lecture covers: R/S configurations on chiral centres and molecules containing 1 or 2 chiral centres). Enantiomers and diastereomers are also introduced in class 1.

Just before the Class 2 starts, the instructor sets up the active learning classroom.

There are 7 tables, each with 3 wings; at each wing of the table, the instructor sets up a list containing the IUPAC names of 2 different molecules (for a total of 6 different molecules per table). Each different table will have instructions to draw a molecule using one type of drawing and then convert to a different type for combinations of the following: Fisher Projection, Newman Projection, or 3D structure (6 different possibilities total); for example, at one table, students can be asked to convert from Fisher Projection to 3D structure (or vice versa).

At the beginning of Class 2, students divide themselves into groups of 2 to 4 and 1 group sits at 1 wing of a table.

The instructor gives a mini lesson on drawing a few using 3D models (using the organic chemistry building kit). This is done by showing the 3D model using a video recorder that is projected onto the wall. Note that the Fisher Projections has not yet been taught; students will teach themselves by doing this activity.

Each group works the together to build a 3D model of both molecules they are assigned using their organic chemistry building kits.

Students then work together to draw a molecule using one type of drawing and then converted to another (whichever combination was assigned to them).

Students individually write a methodology on the steps they did in order to draw the molecule for one type of drawing and how they converted to another (for example which way did they hold the molecule, which way do they turn it etc.). For this exercise, students often take pictures of their 3D models they have built using their cell phones or laptops.

Students have approximately 10 minutes at one table, before they had to move to the next table and make their way around the 7 tables within the 1.5 hour class.

Read Less -

Objectives

To develop a method for interconverting structural representations.

To learn different types of structural representations.

To understand the relationships between different stereoisomers (enantiomers and diastereomers).

Context and requirements

Level College/University
Discipline Chemistry
Course Organic Chemistry
Technological Requirements Molecular Model kit, document camera, cell phone or laptop (a device with which to take pictures).
Best Use Practice, Preparation

Author’s Notes

Benefits

Stereochemistry and conversions from one molecule drawing type to another is difficult for students to visualize, and this activity helps with the 3D visualization of these molecules using different drawing techniques, group work, 3D models, and conversion of one drawing technique to another. This also covers a portion of what students would normally at do at home in class.

Challenges

This activity cuts into teaching time (there is one less class to cover all of the required content). It is challenging for students to understand that an activity in the class is equivalent to the instructor teaching materials.

Tips

This cannot be done in an auditorium, it requires tables where students can interact. This activity can be modified to emphasize the stereochemical features used in reactions and mechanisms.

Activity Pedagogical Components

Model-based Learning

IN A GROUP, students construct a 3D model using their organic chemistry building kit in order to visualize an organic molecule from different views and also how it rotates about its bonds. This is done IN CLASS.

Distributed Problem Solving

IN A GROUP, students construct a 3D model of an assigned molecule and then draw it using one type of drawing and then convert it to another (possible drawing types include: Fisher Projection, Newman Projection, and 3D structure). This is done IN CLASS.

Toolkit

INDIVIDUALLY, students construct methodologies for conversion of one molecule drawing type to another (possible drawing types include: Fisher Projection, Newman Projection, and 3D structure). This is done IN CLASS.

Download Flowchart
